● 50Hz- 20kHz Frequency Response
● 132dBSPL Max @ 1m
● 90° Horizontal coverage
● 60° Vertical coverage
● 1" with waveguide HF compression driver
● 5.5" Stereo coaxial drivers
● 12" LF woofer
● HF- center (Amp): Class AB (Type), 153W (Peak), 80W sine continuous @1% THD (RMS)
● MF + HF - stereo (Amp): Class D (Type), 2 x 153W (Peak), 2x80W sine continuous @1% THD (RMS)
● LF (Amp): Class D (Type), 1200W (Peak), 440W sine continuous @1% THD (RMS)
● Monitor inputs (0- +20dB): XLR/ 1/4" Combi, balanced – 20k ohm – 13dBu
● FX returns: 1/4" TS – 10k ohm – 7dBu
● Guitar input: 1/4" TS – 1M ohm – 12dBu
● Fx sends: 1/4" TS - 680 ohm/2.74k ohm (line/stomp) - 6dBu (stomp mode), 19dBu (line)
● Main XLR outputs: XLR, balanced – 680 ohm – 6dBu
● Headphone outputs: 1/4" TRS – 47.5 ohm – 6dBu
● 5- pin DIN Midi I/O
● Ethercon (Variax)
● RJ 45 (FBV 3)
● USB- B
● IEC power connector, 100-240VAC, 50/60 Hz
● 15mm- 32mm plywood, braced, ported enclosure
● L 661.5*W288 *H505mm (not including handle)
● L 26.04”*W11.34”*H19.88”
● 28.95 kg (63.14 lbs)
● Create, save and recall unlimited presets in the cloud
● Search a cloud-based library of thousands of tones
● Remotely control amp parameters to dial in your sound
● Share tones via Twitter and Facebook
● Made for iPhone® 6 Plus, iPhone 6, iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s, iPhone 4, iPad® (3rd and 4th generation), iPad 2, iPad mini and iPod touch® (5th generation) and compatible Android devices running OS v4.2 or better (visit Line6.com/android for details)
